12 Disturbance Analyzer Measurement
Marker Function
Marker Function
Accesses a menu of keys that allows you to do marker zoom related functions.
Key Path
Front-panel key
Notes Front panel only.
Initial S/W Revision A.14.00
Marker Zoom
Marker zoom will show traces data to the entire graticule display by magnifying 10% of the current traces
data on the selected marker.
Key Path
Marker Function
Remote Command
CALCulate:DANalyzer:MARKer[1]|2|...|12:FUNCtion:ZOOM
Example CALC:DAN:MARK1:FUNC:ZOOM
Notes Command Only
Dependencies Marker Zoom function is not available if the new traces range is out of limit of the Min value of x-
scale/div after magnifying the traces
Couplings The Ref Value and Scale/Div will be changed to accommodate the new span when disturbance zoom
is executed.
Initial S/W Revision A.14.00
Marker Zoom Out
Marker zoom out will return the graticule display back to the previous marker zoom display range.
Key Path
Marker Function
Remote Command
CALCulate:DANalyzer:MARKer[1]|2|...|12:FUNCtion:ZOOM:OUT
Example CALC:DAN:MARK1:FUNC:ZOOM:OUT
Notes Command Only
Dependencies Marker Zoom Out key is not available if the Marker Zoom has not executed
Couplings The Ref Value and Scale/Div will be changed to accommodate the new span when disturbance zoom
is executed.
Backwards
Compatibility SCPI
CALCulate:DANalyzer:MARKer[1]|2|...|12:FUNCtion:PREVious:ZOOM
Initial S/W Revision A.14.00
Marker Zoom Out Full
Marker Zoom Out Full will be restored back to the previous marker zoom range completely.
1044 EMI Receiver Mode Reference
