8 Frequency Scan Measurement
Save
.lim file format
This is a legacy format which allows files saved from older analyzers to be loaded into the X-Series.
Design of files in this format is not recommended.
Signal List
Pressing this key selects Signal List as the data type to be exported with a save request. The next step is to
select the Save As key in the Save Data menu.
See "Signal List File" on page 554 for an example of data contained in the list.
Key Path
Save, Data
Remote Command
:MMEMory:STORe:SLISt <filename>
Example MMEM:STOR:SLIS “C:\My Documents\EMI\data\mySignalList2.csv”
exports the Signal List to the file mySignalList2.csv in the default path.
Notes The default path is at “My Documents\EMI\data\FSCAN\SignalList\SignalL_xxxx.csv”
If the save is initiated via SCPI, and the file already exists, the file will be overwritten.
Using the C: drive is strongly discouraged, since it runs the risk of being overwritten during an
instrument software upgrade.
Both single and double quotes are supported for any filename parameter over SCPI.
Initial S/W Revision A.07.00
Signal List File
A Signal List file contains a copy of one of the signal lists obtained during measurement. The first four lines
are system required header lines, and must be in the correct order.
SignalList DataFileTypeName
EMI:FSCAN Mode Name: Measurement Name
A.01.05N9020A InstrumentVersion ModelNumber
K03 EMC SEC BBA P13 P08 BAB 5031 OptionList FileFormatVersion
The data follows as comma separated values. A keyword “DATA” precedes the data. Here is an example of
signal list file with five signals on it:
SignalList
EMI:FSCAN
A.01.05,N9020A
B1X P13 EA3 BBA B2X ERC UK6 BAB EMC K03 B25 503 P08 526 508 513 S40 P26 B1C HBA P03 PFR ,01
Detector Limit,1,2,3
Final Detector,Peak,Sample,Average
Y Axis Unit,DecibelMicrovolt
DATA
554 EMI Receiver Mode Reference
