8 Frequency Scan Measurement
Meas Setup
Peak Criteria Only
When this key is selected, performing search or issuing the equivalent remote command will add peaks
into the signal list, subject to the peak-criteria qualifications defined in section"Peak Criteria" on page 516
Key Path
Meas Setup, Limits, Search Criteria
Example FSC:SEAR:MODE PONL
Readback Text Peak Criteria Only
Initial S/W Revision A.07.00
Peak Criteria and Limits
When this key is selected, performing a search or issuing the equivalent remote command will add peaks
that meet the limits and margin that is turned on into the signal list. The search is also subject to the peak-
criteria qualifications defined in section"Peak Criteria" on page 516.
Key Path
Meas Setup, Limits, Search Criteria
Example FSC:SEAR:MODE PLIM
Readback Text Pk Crit and Limits
Initial S/W Revision A.07.00
Subranges and Limits
When this key is selected, performing a search or issuing the equivalent remote command will divide the
whole frequency range into equal width subranges. The peak will be determined for each subranges and
peaks that exceed the limits and margin that is turned on will be added into the signal list.
Key Path
Meas Setup, Limits, Search Criteria
Example FSC:SEAR:MODE SLIM
Readback Text Subranges & Limits
Initial S/W Revision A.11.00
# of Peaks
When turned on, determines how many peaks to find during Search when Search Criteria is set to “Peak
Criteria Only” or “Peak Criteria and Limits”.
Key Path
Meas Setup, Limits, Search Criteria
Remote Command
[:SENSe]:FSCan:SEARch:PEAK:COUNt <integer>
[:SENSe]:FSCan:SEARch:PEAK:COUNt?
[:SENSe]:FSCan:SEARch:PEAK:COUNt:STATe ON|OFF|1|0
[:SENSe]:FSCan:SEARch:PEAK:COUNt:STATe?
EMI Receiver Mode Reference 495
