5 Mode Functions
Mode Setup
OFF
Remote control deactivated
This query will return :-
FOUR when ESH2-Z5 is selected.
Preset Set to off on a "Restore Input/Output Defaults"
State Saved Saved in instrument state
Initial S/W Revision A.13.50
Phase
This command enables you to select the phase of the V-network that is used, which is controlled via the
AUX IO port. The permissible selection depends on the selected V-network.
Key Path
Mode Setup, LISN Control, ESH2Z5/ENV216
Remote Command
INPut[1]|2:LISN:PHASe L1|L2|L3|N
INPut[1]|2:LISN:PHASe?
Example :INP:LISN:PHAS L1
Couplings Phase N|L1|L2|L3 are grayed out with OFF whereas Phase L2|L3 are grayed out with ENV216. If the
grayed out key is pressed, an advisory message is generated. If the equivalent SCPI command is sent,
this same message is generated as part of a “–221, Setting Conflict; Function not available with
current LISN Type” warning.
Preset Set to N on a "Restore Input/Output Defaults"
State Saved Saved in instrument state
Range Phase N|Phase L1|Phase L2|Phase L3
Only one phase can be selected.
Initial S/W Revision A.13.50
Protective Earth
Enables you to set the Protective Earth setting that is controlled via the AUX IO port.
Key Path
Mode Setup, LISN Control, ESH2Z5
Remote Command
INPut[1]|2:LISN:PEARth GROunded|FLOating
INPut[1]|2:LISN:PEARth?
Example :INP:LISN:PEAR GRO
Dependencies This key is grayed out when V-network other than ESH2Z5 is selected. If the grayed out key is
pressed, an advisory message is generated. If the equivalent SCPI command is sent, this same
message is generated as part of a “–221, Setting Conflict; Function not available with current LISN
Type” warning.
Preset Set to GRO on a "Restore Input/Output Defaults"
EMI Receiver Mode Reference 261
