8 Frequency Scan Measurement
Meas Setup
Key Path
Meas Setup, Scan Table
Remote Command
[:SENSe]:FSCan:SCAN[1]|2|...|10:RULes PRBW|LPCT
[:SENSe]:FSCan:SCAN[1]|2|...|10:RULes?
Example FSC:SCAN3:RUL LPCT Set Range 3 to use auto rules of Log % of Freq
FSC:SCAN3:RUL?
Dependencies This key is grayed out during multi range scanning. If the grayed out key is pressed, an advisory
message is generated. If the equivalent SCPI command is sent, this same message is generated as
part of a “–221, Settings conflict; Function not available while running multirange scan” warning.
This key is grayed out during final measurement. If the grayed out key is pressed, an advisory
message is generated. If the equivalent SCPI command is sent, this same message is generated as
part of a “–221, Settings conflict” warning.
Couplings Changing Auto Step Size Rules will automatically change the step size of the selected range to Auto.
Preset PRBW
State Saved Saved in instrument state.
Range Points/RBW | Log % of Freq
Readback If Auto Step Size Rules is Points/RBW, [Points/RBW,<int>]
If Auto Step Size Rules is Log % of Freq, [Log %,<int>]
Initial S/W Revision A.07.00
Points/ RBW
Choose the Step Size to change automatically based on number of Points/ RBW
Key Path
Meas Setup, Scan Table, Auto Step Size Rules
Example FSC:SCAN:RUL PRBW Selects the Points/RBW Auto Step Rules for range 1.
Couplings Selecting the points/RBW will cause the step size of the selected range to turn into Auto, even if it
was already selected.
Initial S/W Revision A.07.00
Specifies the value of Point/ RBW for the selected Range.
Key Path
Meas Setup, Scan Table, Auto Step Size Rules
Remote Command
[:SENSe]:FSCan:SCAN[1]|2|...|10:PRBW <integer>
[:SENSe]:FSCan:SCAN[1]|2|...|10:PRBW?
Example FSC:SCAN2:PRBW 2 Set 2 points/ RBW for Range 2.
FSC:SCAN2:PRBW?
Dependencies This key is grayed out during multi range scanning. If the grayed out key is pressed, an advisory
message is generated. If the equivalent SCPI command is sent, this same message is generated as
part of a “–221, Settings conflict; Function not available while running multirange scan” warning.
This key is grayed out during final measurement. If the grayed out key is pressed, an advisory
EMI Receiver Mode Reference 463
