8 Frequency Scan Measurement
Meas Setup
message is generated. If the equivalent SCPI command is sent, this same message is generated as
part of a “–221, Settings conflict” warning.
This key is grayed out during Time Domain Scan.If the grayed out key is pressed, an advisory message
is generated. If the equivalent SCPI command is sent, this same message is generated as part of a “–
221, Settings conflict; Function not available with time domain scan type” warning. During Time
Domain Scan, the value is automatically set to 4. Changing to another Scan Type from Time Domain
to another scan type does not restore the previous value.
Preset 2
State Saved Saved in instrument state.
Min 1
Max 4
Initial S/W Revision A.07.00
Log % of Freq
Choose the Step Size to change automatically incremented in % of the current frequency.
Key Path
Meas Setup, Scan Table, Auto Step Size Rules
Example FSC:SCAN:RUL LPCT Selects the Points/RBW Auto Step Rules for range 1.
Dependencies This key is grayed out when the Scan type is set to Smoothand Time Domain If the grayed out key is
pressed, an advisory message is generated. If the equivalent SCPI command is sent, this same
message is generated as part of a “–221, Settings conflict” warning.
Couplings Selecting the Log % of Freq will cause the step size of the selected range to turn into Auto, even if it
was already selected.
Initial S/W Revision A.07.00
Key Path
Meas Setup, Scan Table, Step Control, Auto Step Size Rules
Remote Command
[:SENSe]:FSCan:SCAN[1]|2|...|10:LPCT <integer>
[:SENSe]:FSCan:SCAN[1]|2|...|10:LPCT?
Example FSC:SCAN2:LPCT 2 Set the Range 3 to make log scan using 2% of current frequency.
FSC:SCAN2:LPCT?
Dependencies This key is grayed out when the Scan type is set to Smooth and Time DomainIf the grayed out key is
pressed, an advisory message is generated. If the equivalent SCPI command is sent, this same
message is generated as part of a “–221, Settings conflict” warning.
This key is grayed out during multi range scanning. If the grayed out key is pressed, an advisory
message is generated. If the equivalent SCPI command is sent, this same message is generated as
part of a “–221, Settings conflict; Function not available while running multirange scan” warning.
This key is grayed out during final measurement. If the grayed out key is pressed, an advisory
message is generated. If the equivalent SCPI command is sent, this same message is generated as
part of a “–221, Settings conflict” warning.
464 EMI Receiver Mode Reference
