10 Monitor Spectrum Measurement
Meas Setup
SCPI Notes measurement, they are added solely for remote language compatibility.
Initial S/W Revision A.13.00
Trace Fail? (Remote Command Only)
Tests a trace against all associated limit lines. Returns a 0 if the trace is within all limits and margins, a 1 if
the trace exceed either the limit or the margin. If no limits apply to the selected trace, this will
automatically return a 0.
Only applies to limits that are turned on, if a Limit is off it will not be tested. If a Trace is not displaying it will
still be tested, and if Test Limits (All Limits) is off the Trace will still be tested.
This command ignores limit lines that are assigned to other traces.
Remote Command
:CALCulate:MONitor:TRACe[1]|2|3:FAIL?
Example CALC:MON:TRAC3:FAIL? returns a zero if there is no failure, 1 if the trace exceeds either the limit or
the margin.
Initial S/W Revision A.13.00
Limit Line Control (Remote Command Only)
Defines a list of limit line control (frequency or time) values for a given limit line. Up to 2000 points may be
defined for each limit using the following parameters.
<x> Frequency or time values as specified by :Calculate:LLINe:CONTrol:DOMain. Units default to Hz (for
frequency) and seconds (for time).
Range: –30 Gs to +30 Gs for time limits, –3 kHz to +1200 GHz for frequency limits.
Remote Command
:CALCulate:LLINe[1]|2|...|6:CONTrol[:DATA] <x>, <x>, …
:CALCulate:LLINe[1]|2|...|6:CONTrol[:DATA]?
Example CALC:LLIN:CONT 1GHz, 2GHz, 2GHz, 3GHz Describes the X values of a stair-stepped limit line.
CALC:LLIN:CONT?
Preset Unaffected by Preset
State Saved Saved in instrument state
Backwards
Compatibility SCPI
:CALCulate[1]|2:LIMit[1]|2|...|6:CONTrol[:DATA]
Backwards Compatibility
SCPI Notes
This command above is included for ESU compatibility. The suffix 1|2 is irrelevant to the
measurement, they are added solely for remote language compatibility.
Initial S/W Revision A.13.00
Remote Command
:CALCulate:LLINe[1]|2|...|6:CONTrol:POINts?
EMI Receiver Mode Reference 803
