8 Frequency Scan Measurement
Peak Search
Peak Search Criteria
This menu lets you decide the mode of Peak Search. When Highest Peak is selected, pressing Peak Search
finds the highest peak on the marker’s trace. If Same as “Next Peak” Criteria is selected, then the search is
also forced to consider the Excursion and Threshold found under the “Next Peak” Criteria menu.
Key Path
Peak Search, Peak Criteria
Remote Command
:CALCulate:FSCan:MARKer:PEAK:SEARch:MODE MAXimum|PARameter
:CALCulate:FSCan:MARKer:PEAK:SEARch:MODE?
Example CALC:FSC:MARK:PEAK:SEAR:MODE MAX
Notes MAXimum corresponds to the Highest Peak setting
PARameter corresponds to the Same as “Next Peak” Criteria setting
Preset MAXimum
State Saved Saved in instrument state.
Range Highest Peak| Same as “Next Peak” Criteria (Exc & Threshold)
Readback Text Current state
Initial S/W Revision A.07.00
Highest Peak
When this key is selected, pressing the Peak Search key or issuing the equivalent remote command finds
the maximum point on the trace, subject to the peak-search qualifications.
Key Path
Peak Search, Peak Criteria, “Peak Search” Criteria
Example CALC:FSC:MARK:PEAK:SEAR:MODE MAX
Readback Text Highest Peak
Initial S/W Revision A.07.00
Same as “Next Peak” Criteria
When this key is selected, pressing the Peak Search key or issuing the equivalent remote command finds
the maximum point on the trace, but subject to the Excursion and Threshold set under the Next Peak
Criteria menu. The search is also subject to the peak-search qualifications. This also affects the
Continuous Peak Search.
Key Path
Peak Search, Peak Criteria, “Peak Search” Criteria
Example CALC:FSC:MARK:PEAK:SEAR:MODE PAR
Readback Text Same as Next Pk
Initial S/W Revision A.07.00
EMI Receiver Mode Reference 517
