11 APD Measurement
Recall
Couplings When a correction file is loaded from mass storage, it is automatically turned on (Correction ON) and
ApplyCorrections is set to On. This allows you to see its effect, thus confirming the load.
Readback selected Correction
Backwards
Compatibility SCPI
:MMEMory:LOAD:CORRection ANTenna | CABLe | OTHer | USER, <filename>
For backwards compatibility, ANTenna maps to 1, CABle maps to 2, OTHer maps to 3 and USER
maps to 4
Initial S/W Revision A.02.00
Default Directory
Specifies the default directory used for loading of Amplitude Correction. If user is selected, the default
recall directory is the default (My Documents\amplitudeCorrections) or the last directory you saved the
amplitude correction data to. Otherwise, the default recall directory is My Documents\EMC Limits and
Ampcor\Ampcor, which contains a set of preloaded amplitude correction files in the directory called
Ampcor.
Key Path
Recall, Export Data, Amplitude Correction
Remote Command
:MMEMory:LOAD:CORRection:DDIRectory USER|PRELoaded
Example :MMEM:LOAD:CORR:DDIR USER Select user
:MMEM:LOAD:CORR:DDIR?
Notes USER = User
PRELoaded = Preloaded
Preset PRELoaded
State Saved Saved in instrument state.
Range User| Preloaded
Readback “User”| “Preloaded”
Initial S/W Revision A.13.00
Trace
This key selects Trace as the data type to be imported. When pressed a second time, it brings up the Trace
Menu, which lets you select the Trace into which the data will be imported.
Key Path
Recall, Data
Remote Command
:MMEMory:LOAD:ATRace MEAS|MEAS2,<filename>
Example :MMEM:LOAD:ATR MEAS2, "myTrace2.csv" imports the Measured 2 Trace from the file
myTrace2.csv in the current path. The default path is My Documents\EMI\data\APD\Traces.
Dependencies A trace cannot be recalled from a trace file that was exported with ALL traces selected.
A trace cannot be imported if the number of trace points in the file does not match the number of
EMI Receiver Mode Reference 973
