11 APD Measurement
Save
19.46919986 0.638484031
19.56330081 0.632386608
19.65740176 0.626085183
19.75150272 0.619035746
19.84560367 0.612008976
19.93969699 0.604778203
20.03379794 0.598635447
20.1278989 0.592334021
20.22199985 0.585579255
20.3161008 0.578461817
Limit
Pressing this key selects Limit Lines as the data type to be exported. Pressing the key a second time brings
up the Limit Menu that allows you to select which Limit Line to save. However, currently there is only 1 limit
line for the APD measurement.
Key Path
Save, Data
Remote Command
:MMEMory:STORe:ALIMit LLINE1,<filename>
Example :MMEM:STOR:ALIM LLINE1, " myAPDLimit.csv" saves the Limit Line to the file myAPDLimit.csv in
the current path. The default path is My Documents\EMI\data\APD\Limits.
Notes If the save is initiated via SCPI, and the file already exists, the file will be overwritten.
Using the C: drive is strongly discouraged, since it runs the risk of being overwritten during an
instrument software upgrade.
Both single and double quotes are supported for any filename parameter over SCPI.
Dependencies This key will only appear if you have the proper option installed in your instrument.
Preset 1; not part of Preset, but is reset by Restore Mode Defaults and survives power cycles.
State Saved The selected Limit number is saved in instrument state.
Readback Selected Limit Line
Status Bits/OPC
dependencies
Sequential - waits for previous measurement to complete
Initial S/W Revision A.13.00
APD Limit File Content
The following file example shows the Limit file content in comma separated values when the APD Method
is set to:
(a)Disturbance Level
Limit
EMI Receiver Mode Reference 991
