8 Frequency Scan Measurement
Meas Setup
Settings
This menu enables you to access the LISN control menu.
Key Path
Meas Setup, LISN Control
ReadBack [<Phase>, <HighPass>, <ProtectiveEarth>] in the format of [N|L1|L2|L3|,HP,GRO|FLO]
HP would be shown when the 150KHz HighPass is turn on. GRO stands for is for grounded and FLO
stands for floating.
Initial S/W Revision A.13.50
Phase
Selects the phases of the V-network.
Key Path
Meas Setup, LISN Control, Settings
Remote Command
:SENSe1|SENSe2|[SENSe]:FMEasurement:LISN:PHASe L1 | L2 | L3 | N[[,L1 |
L2 | L3 | N],.]
:SENSe1|SENSe2|[SENSe]:FMEasurement:LISN:PHASe L1 | L2 | L3 | N[[,L1 |
L2 | L3 | N],.]
Example FME:LISN:PHAS L1
Notes L2 and L3 are only available in ESH2Z5 (or set to FOURphase)
Dependencies Phase N|L1|L2|L3 are grayed out with OFF whereas Phase L2|L3 are grayed out with ENV216. If the
grayed out key is pressed, an advisory message is generated. If the equivalent SCPI command is sent,
this same message is generated as part of a “–221, Setting Conflict; Function not available with
current LISN Type” warning.
This key is grayed out when a scan sequence is running. If the grayed out key is pressed, an advisory
message is generated. If the equivalent SCPI command is sent, this same message is generated as
part of a “–221, Settings conflict” warning.
Couplings If users try to turn off all available phases from front panel, an advisory message is generated as “At
least one Phase must be turned on”.
Preset ON
State Saved Saved in instrument state
Range ON|OFF
ON is selected when the specific phase is selected. User can select different phase at the same time.
Initial S/W Revision A.13.50
150 kHz Highpass
Toggles highpass of the V-network.
Key Path
Meas Setup, LISN Control, Settings
Remote Command
:SENSe1|SENSe2|[:SENSe]:FMEasurement:LISN:FILTer:HPAS[:STATe] ON | OFF
| 1 | 0
EMI Receiver Mode Reference 505
