10 Monitor Spectrum Measurement
Save
Trace
EMI:MON
A.13.00 N9038A
526 DP2 EMC LSN 1
Preselector On
Y Axis Unit dBuV
Ref Level Offset 0 dB
Coupling AC
Input Z Correction 50 ohm
DATA
Trace 1
Detector Peak
29740009.9 9.302139008
29741009.9 9.609657014
29742009.9 9.945373261
29743009.9 10.28534671
29744009.9 10.59982272
29745009.9 10.84645816
29746009.9 10.97216769
29747009.9 10.93370792
29748009.9 10.70057651
29749009.9 10.21771213
29750009.9 9.474250519
29751009.9 8.374183381
29752009.9 6.909049714
29753009.9 4.86714145
29754009.9 2.253837311
29755009.9 –0.937874114
29756009.9 –4.154472625
Limit
Pressing this key selects Limit Lines as the data type to be exported. Pressing the key a second time brings
up the Limit Menu that allows you to select which Limit Line to save.
See "Limits File Contents" on page 851.
850 EMI Receiver Mode Reference
