4 Input/Output Functions
Input/Output
Example SENS:CORR:CSET1 ON
Dependencies Changing this from the OFF state to the ON state automatically turns on "Apply Corrections".
Only the first correction array (Correction 1) supports antenna units. When this array is turned on,
and it contains an Antenna Unit other than “None”, the Y Axis Unit of the analyzer is forced to that
Antenna Unit. All other Y Axis Unit choices are grayed out.
Note that this means that a correction file with an Antenna Unit can only be loaded into the
Corrections 1 register. Consequently only for Correction 1 does the dropdown in the Recall dialog
include.ant, and if an attempt is made to load a correction file into any other Correction register
which DOES contain an antenna unit, a Mass Storage error is generated.
This command will generate an “Option not available” error unless you have the proper option
installed in your instrument.
Preset Not affected by a Preset. Set to OFF by Restore Input/Output Defaults
State Saved Saved in instrument state.
Backwards Compatibility
Notes
Unlike legacy analyzers, Preset does not turn Corrections off (Restore Input/Output Defaults does).
Initial S/W Revision A.02.00
Modified at S/W Revision A.14.00
Properties
Accesses a menu that lets you set the properties of the selected correction.
Key Path
Input/Output, Corrections
Initial S/W Revision A.02.00
Select Correction
Specifies the selected correction. The term "selected correction" is used throughout this document to
specify which correction will be affected by the functions.
Key Path
Input/Output, Corrections
Mode SA, I/Q Analyzer, Phase Noise, VXA, RTSA, EMI Receiver, DVB-T/H, DTMB, DVB-T/H, DTMB, W-
CDMA, LTE & LTE-Adv FDD, LTE & LTE-Adv TDD, Sequence Analyzer, BTooth
Notes The selected correction is remembered even when not in the correction menu.
Preset Set to Correction 1 by Restore Input/Output Defaults
Readback Correction 1|Correction 2|Correction 3|Correction 4|Correction 5|Correction
6|Correction7|Correction8
Initial S/W Revision A.02.00
Modified at S/W Revision x.14.50
EMI Receiver Mode Reference 185
