10 Monitor Spectrum Measurement
Recall
Couplings When a correction file is loaded from mass storage, it is automatically turned on (Correction ON) and
ApplyCorrections is set to On. This allows you to see its effect, thus confirming the load.
Readback selected Correction
Backwards
Compatibility SCPI
:MMEMory:LOAD:CORRection ANTenna | CABLe | OTHer | USER, <filename>
For backwards compatibility, ANTenna maps to 1, CABle maps to 2, OTHer maps to 3 and USER
maps to 4
Initial S/W Revision A.02.00
Amplitude Correction
These keys let you select which Correction to import the data into. Once selected, the key returns back to
the Import Data menu and the selected Correction number is annotated on the key. The next step is to
select the Open key in the Import Data menu.
Antenna corrections are a particular kind of Amplitude Corrections – they are distinguished in the
corrections file by having the Antenna Unit set to a value other than None. Only Correction 1 supports
Antenna Units.
Key Path
Recall, Data, Amplitude Correction
Notes auto return
Dependencies Only Correction 1 may be used to load a Correction that contains an Antenna Unit other than None
Preset Not part of Preset, but is reset to Correction 1 by Restore Input/Output Defaults; survives shutdown.
State Saved The current Correction number is saved in instrument state
Initial S/W Revision A.02.00
Default Directory
Specifies the default directory used for loading of Amplitude Correction. If user is selected, the default
recall directory is the default (My Documents\amplitudeCorrections) or the last directory you saved the
amplitude correction data to. Otherwise, the default recall directory is My Documents\EMC Limits and
Ampcor\Ampcor, which contains a set of preloaded amplitude correction files in the directory called
Ampcor.
Key Path
Recall, Export Data, Amplitude Correction
Remote Command
:MMEMory:LOAD:CORRection:DDIRectory USER|PRELoaded
Example :MMEM:LOAD:CORR:DDIR USER Select user
:MMEM:LOAD:CORR:DDIR?
Notes USER = User
PRELoaded = Preloaded
Preset PRELoaded
832 EMI Receiver Mode Reference
