9 Strip Chart Measurement

SPAN X Scale

Displays the menu keys that enable you to control the span x scale parameters.

Key Path

Front-panel key

Notes Front panel only.

Initial S/W Revision A.07.00

Ref Value

Sets the ref value of the strip chart display.

Key Path

SPAN X Scale

Remote Command

:DISPlay:SCHart:VIEW[1]:WINDow[1]:TRACe:X[:SCALe]:RLEVel <time>

:DISPlay:SCHart:VIEW[1]:WINDow[1]:TRACe:X[:SCALe]:RLEVel?

Example DISP:SCH:VIEW:WIND:TRAC:X:RLEV –100 s

DISP:SCH:VIEW:WIND:TRAC:X:RLEV?

Couplings No

Preset 0 s

State Saved Saved in instrument state.

Min –1.1998 ks

Max 0 s

Initial S/W Revision A.07.00

Scale/Div

Allows you to set X scale/div of the strip chart display.

Key Path

SPAN X Scale

Remote Command

:DISPlay:SCHart:VIEW[1]:WINDow[1]:TRACe:X[:SCALe]:PDIVision <time>

:DISPlay:SCHart:VIEW[1]:WINDow[1]:TRACe:X[:SCALe]:PDIVision?

Example DISP:SCH:VIEW:WIND:TRAC:X:PDIV 1s

DISP:SCH:VIEW:WIND:TRAC:X:PDIV?

Preset 1 s

State Saved Saved in instrument state.

704 EMI Receiver Mode Reference
