8 Frequency Scan Measurement
Marker
Delta Marker State (Remote Command Only)
Toggles the Delta marker state on and off.
Remote Command
:CALCulate[1]|2:DELTamarker[1]|2|...|4[:STATe] ON|OFF|1|0
:CALCulate[1]|2:DELTamarker[1]|2|...|4[:STATe]?
Example CALC:DELT3 ON Turn on maker 3 in Delta mode.
Notes This SCPI is Meas Local and Context Sensitive. This SCPI alias to :CALC:FSC:MARK[1]|2|3|4:MODE
DELT.
Preset OFF
Initial S/W Revision A.07.00
Delta Marker X Axis Value (Remote Command Only)
Sets the selected marker to Delta mode, and sets/ gets the marker X Axis values. The command input is in
relative values and refers to the reference marker while the query always returns absolute values in order
to make it compatible with the ESU.
Remote Command
:CALCulate[1]|2:DELTamarker[1]|2|...|4:X <value>
:CALCulate[1]|2:DELTamarker[1]|2|...|4:X?
Example CALC:DELT3:X 3e4 Turn on maker 3 in Delta mode, set the relative delta marker frequency to 30
kHz.
CALC:DELT3:X? Turn on maker 3 in Delta mode and query the absolutes X axis value.
Notes This SCPI is Meas Local and Context Sensitive. This SCPI alias to :CALC:FSC:MARK[1]|2|3|4:MODE
DELT; followed by query of absolutes X Axis unit. The query is different from :CALC:FSC:MARK[1]
|2|3|4:X? that returns the relative X Axis unit when marker in Delta mode.
Preset 0
Initial S/W Revision A.07.00
Delta Marker Y Axis Value (Remote Command Only)
Sets the selected marker to Delta mode, and returns the marker Y Axis values. The output is always a
relative value referenced to a reference marker.
Remote Command
:CALCulate[1]|2:DELTamarker[1]|2|...|4:Y?
Example CALC:DELT3:Y? Turn on maker 3 in Normal mode and query the Y axis relative value.
Notes This SCPI is Meas Local and Context Sensitive. This SCPI alias to :CALC:FSC:MARK[1]|2|3|4:MODE
DELT;:CALC:FSC:MARK[1]|2|3|4:Y?
Initial S/W Revision A.07.00
416 EMI Receiver Mode Reference
