8 Frequency Scan Measurement
Recall
Scan Table
Selects the scan table as the data type to be imported.
Key Path
Recall, Data
Remote Command
:MMEMory:LOAD:SCAN <filename>
Example MMEM:LOAD:SCAN “myScanTable1.csv”
Imports the Scan Table from the file myScanTable1.csv in the default path.
Notes If the file is empty, error –250.3005 is reported. If the file does not exist error –256 is reported. If
there is a mismatch between the file and the destination data type, an error is reported. –250.3003.
Then return to the Import Data menu and File Open dialog goes away.
Before loading a signal list file, any running scan sequence will be stopped.
Couplings No
Status Bits/OPC
Dependencies
Sequential - aborts the current measurement
Initial S/W Revision A.07.00
Open…
When you press “Open”, the analyzer brings up a Windows dialog and a menu entitled “File Open.” This
menu allows you to navigate to the various fields in the Windows dialog without using a keyboard or
mouse. The Tab and Arrow keys can also be used for dialog navigation.
See "From File…" on page 1083in Recall, State, for a full description of this dialog and menu.
Key Path
Recall, Data
Notes The key location is mode-dependent and will vary.
Brings up Open dialog for recalling a <mode specific> Save Type
Initial S/W Revision Prior to A.02.00
State
Most of the functions under this key work the same way in many measurements, so they are documented
in the Utility Functions section. For details about this key, see "State" on page 1081.
Data (Import)
Most of the functions under this key work the same way in many measurements, so they are documented
in the Utility Functions section. For details about this key, see "Data (Import)" on page 1086.
Amplitude Correction
Most of the functions under this key work the same way in many measurements. For details about this key,
see "Amplitude Correction " on page 1087.
EMI Receiver Mode Reference 533
