10 Monitor Spectrum Measurement

Marker

Access the Marker menu. The functions in this menu include a 1-of-N selection of the control mode

Normal, Delta or Off for the selected marker. If the selected marker is Off, pressing Marker sets it to Normal

and places it at the center of the screen on the trace determined by the Marker Trace rules. At the same

time, the reference value of the selected marker appears on the Active Function area.

The marker X axis value entered in the active function area will display the marker value to its full entered

precision.

Key Path

Front-panel key

Remote Command

:CALCulate:MONitor:MARKer[1]|2|...|12:MODE POSition | DELTa | OFF

:CALCulate:MONitor:MARKer[1]|2|...|12:MODE?

Example CALC:MON:MARK:MODE OFF

CALC:MON:MARK:MODE?

Notes If the selected marker is Off, pressing Marker sets it to Normal and places it at the center of the

screen on the trace determined by the Marker Trace rules. At the same time, Marker X Axis Value

appears in the Active Function area.

Default Active Function: the active function for the selected marker’s current control mode. Note

that if the current control mode is Off, there is no active function and the active function is turned off.

Active Function Display: the marker X axis value entered in the active function area will display the

marker value to its fully entered precision.

Preset OFF

State Saved Saved in instrument state

Initial S/W Revision A.13.00

Select Marker

Display a menu with 12 markers available for selection for the current measurement.

Key Path

Marker

Notes Front panel only. The selected marker is remembered even when not in the Marker menu and is used

Preset Marker 1

State Saved Saved in instrument state

Initial S/W Revision A.13.00

Normal

Sets the control mode for the selected marker to Normal and turns on the active function for setting its

value. If the selected marker was off, it is placed at the center of the screen on the trace specified by the

marker’s Trace attribute.

758 EMI Receiver Mode Reference
