6 System Functions
System
Key Path
System, Alignments, Advanced
Mode All
Remote Command
:CALibration:TDS
Example :CAL:TDS
Notes See SCPI for Align Piece
Initial S/W Revision A.13.0
Timebase DAC
Allows control of the internal 10 MHz reference oscillator timebase. This may be used to adjust for minor
frequency alignment between the signal and the internal frequency reference. This adjustment has no
effect if the instrument is operating with an External Frequency Reference.
If the value of the Timebase DAC changes (by switching to Calibrated from User with User set to a different
value, or in User with a new value entered) an alignment may be necessary. The alignment system will
take appropriate action; which will either invoke an alignment or cause an Alert.
Key Path
System, Alignments
Mode All
Remote Command
:CALibration:FREQuency:REFerence:MODE CALibrated|USER
:CALibration:FREQuency:REFerence:MODE?
Example :CAL:FREQ:REF:MODE CAL
Notes If the value of the timebase is changed the alignment system automatically performs an alignment or
alerts that an alignment is due.
If the value of the timebase is changed the alignment system automatically performs an alignment or
alerts that an alignment is due.
Preset This is unaffected by Preset but is set to CALibrated on a “Restore System Defaults->Align”.
State Saved No
Initial S/W Revision Prior to A.02.00
Calibrated
Sets the Timebase DAC to the value established during factory or field calibration. The value displayed on
the menu key is the calibrated value.
Key Path
System, Alignments, Timebase DAC
Mode All
Example :CAL:FREQ:REF:MODE CAL
Readback Text [xxx] < where xxx is the calibrated value
Initial S/W Revision Prior to A.02.00
322 EMI Receiver Mode Reference
