6 System Functions
System
System
Opens a menu of keys that access various configuration menus and dialogs.
Key Path
Front-panel key
Notes No remote command for this key specifically.
Initial S/W Revision Prior to A.02.00
Show
Accesses a menu of choices that enable you to select the information window you want to view.
Key Path
System
Mode All
Remote Command
:SYSTem:SHOW OFF | ERRor | SYSTem | HARDware | LXI | HWSTatistics |
ALIGnment | SOFTware | CAPPlication
:SYSTem:SHOW?
Example :SYST:SHOW SYST
Notes This command displays (or exits) the various System information screens.
Preset OFF
State Saved No
Range OFF| ERRor | SYSTem | HARDware | LXI | HWSTatistics | ALIGNment | SOFTware|CAPPlication
Initial S/W Revision Prior to A.02.00
Errors
There are two modes for the Errors selection, History and Status.
The list of errors displayed in the Errors screen does not automatically refresh. You must press the Refresh
key or leave the screen and return to it to refresh it.
History brings up a screen displaying the event log in chronological order, with the newest event at the top.
The history queue can hold up to 100 messages (if a message has a repeat count greater than 1 it only
counts once against this number of 100). Note that this count bears no relation to the size of the SCPI
queue. If the queue extends onto a second page, a scroll bar appears to allow scrolling with a mouse. Time
is displayed to the second.
Status brings up a screen summarizing the status conditions currently in effect. Note that the time is
displayed to the second.
The fields on the Errors display are:
Type (unlabeled) - Displays the icon identifying the event or condition as an error or warning.
ID - Displays the error number.
Message - Displays the message text.
272 EMI Receiver Mode Reference
