3 Programming the Analyzer
STATus Subsystem
Operation Enable
This command determines which bits in the Operation Event register, will set the Operation Status
Summary bit (bit 7) in the Status Byte Register. The variable <integer> is the sum of the decimal values of
the bits you want to enable.
The preset condition is to have all bits in this enable register set to 0. To have any Operation Events
reported to the Status Byte Register, one or more bits need to be set to 1.
Mode All
Remote Command
:STATus:OPERation:ENABle <integer>
:STATus:OPERation:ENABle?
Example STAT:OPER:ENAB 1 Sets the register so that Align Now operation will be reported to the Status Byte
Register.
Preset 0
Min 0
Max 32767
Status Bits/OPC
dependencies
Sequential command
Initial S/W Revision Prior to A.02.00
Operation Event Query
This query returns the decimal value of the sum of the bits in the Operation Event register.
The register requires that the associated PTR or NTR filters be set before a condition register bit can set a
bit in the event register. The data in this register is latched until it is queried. Once queried, the register is
cleared.
Mode All
Remote Command
:STATus:OPERation[:EVENt]?
Example STAT:OPER?
Preset 0
Status Bits/OPC
dependencies
Sequential command
Initial S/W Revision Prior to A.02.00
Operation Negative Transition
This command determines which bits in the Operation Condition register will set the corresponding bit in
the Operation Event register when the condition register bit has a negative transition (1 to 0). The variable
<integer> is the sum of the decimal values of the bits that you want to enable.
