5 Mode Functions
Mode Setup
Limit
Enables you to set a limit value for meters.
Key Path
Mode Setup, Meters Control, Meters
Remote Command
:C
ALC
ul
ate
:M
ETe
r[
1]|
2|
3:L
IM
it[
:D
ATA
]
<am
pl
>
:CALCulate:METer[1]|2|3:LIMit[:DATA]?
:CALCulate:METer[1]|2|3:LIMit:STATe ON|OFF|1|0
:CALCulate:METer[1]|2|3:LIMit:STATe?
Example CALC:MET2:LIM 4dBuV Set the limit line of Meter 2 to 4 dBuV.
:CALC:MET:LIM:STAT OFF ! Turns off the limit for Meter 1.
Preset 80 dBuV
OFF
State Saved Saved in instrument state.
Min –250 dBuV
Max 250 dBuV
Default Unit Depends on the current selected Y axis unit
Initial S/W Revision A.07.00
Limit Fail? (Remote Command Only)
Tests a limit line against its associated meter. Returns a 0 if the meter is within the limit, a 1 if the meter
exceeds either limit.
Note that this command only tests one limit line – other limit lines are not tested when executing this
command. To see whether meters passed all limits, use :CALCulate:METer:LIMit:ALL:FAIL?.
Note that this command performs the test regardless of whether the meter or the limit is turned on, on the
display.
Key Path
Remote command only
Remote Command
:CALCulate:METer[1]|2|3:LIMit:FAIL?
Example CALC:MET:LIM:FAIL? Returns a zero if limit line 1’s associated meter is within limit, 1 if the
associated meter failed the limit.
Initial S/W Revision A.07.00
All Limit Fail? (Remote Command Only)
Tests all limit lines of meters. Returns 0 if all meters are within the limit, otherwise returns 1. If no limits
apply to meters, this query will return a 0.
Only applies to meters that have limits turned on, if a Limit is off, it will not be tested.
EMI Receiver Mode Reference 251
