5 Mode Functions
Mode Setup
Couplings Selecting a detector for a meter (pressing the key or sending a [:SENS]:MET:DET command) puts the
meter in On, even if that detector was already selected.
Voltage averaging will be used.
Preset POSitive|QPEak|EAVerage
State Saved Saved in instrument state
Range Peak|Quasi Peak|EMI Average|RMS Average|Negative Peak
Initial S/W Revision A.07.00
Key Path
Remote command only
Remote Command
:SENSe1|SENSe2|[SENSe]:DETector:RECeiver[:FUNCtion] POSitive | NEGative
| RMS | AVERage | QPEak | CAVerage | CRMS,POSitive | NEGative | RMS |
AVERage | QPEak | CAVerage | CRMS,POSitive | NEGative | RMS | AVERage |
QPEak | CAVerage | CRMS
:SENSe1|SENSe2|[SENSe]:DETector:RECeiver[:FUNCtion]?
Example DET:REC AVER
Notes This command is included for ESU compatibility. The suffix [1]|2 is irrelevant to the measurement,
they are added solely for remote language compatibility.
This SCPI can receive up to 3 detector types, the detector types are separated by a comma. The 2nd
and 3rd parameters in the command are optional. For example, for the case where two detectors are
sent, the command will look like this DET:REC POS,QPE. The first detector refers to meter 1
detector, while the latter refers to meter 2 detector.
This command is alias to [:SENSe]:METer[1]|2|3:DETector <DectectorType>, :DISPlay:METer[1]|2|3
[:STATe] ON.
POSitive Peak
NEGative Negative Peak
RMS/ CRMS RMS Average
CAVerage EMI Average
AVERage Average
QPEak Quasi Peak
The query will return the selected meter detector.
CAV when EMI Average is selected.
CRMS when RMS Average is selected.
Couplings The number of detector parameters sent corresponds to the number of the meter being turned on,
which means if there are 2 detector parameters sent, meter 1 and 2 will be turned on, and meter 3
will be turned off.
Preset POSitive
Initial S/W Revision A.07.00
250 EMI Receiver Mode Reference
