8 Frequency Scan Measurement
View/ Display
display area.
Key Path
View/ Display
Remote Command
:DISPlay:FSCan:VIEW:METer[:STATe] ON|OFF|1|0
:DISPlay:FSCan:VIEW:METer[:STATe]?
Example :DISP:FSC:VIEW:MET 1
:DISP:FSC:VIEW:MET?
Preset ON
State Saved Saved in instrument state.
Initial S/W Revision A.07.00
Meters Freq Line
When on, a blue vertical line showing the location of the meters frequency will appear on the frequency
scan graph. In the signal list, the signal number is the same color as the Meters Freq Line when the Meters
Freq is matched with the signal’s frequency. Otherwise, the signal number is in white.
Key Path
View/ Display
Remote Command
:DISPlay:FSCan:VIEW:METer:FLINe ON|OFF|1|0
:DISPlay:FSCan:VIEW:METer:FLINe?
Example :DISP:FSC:VIEW:MET:FLIN 1
:DISP:FSC:VIEW:MET:FLIN?
Dependencies The Frequency Line will only be shown if Meters Display is set to on and when a scan is not running.
Preset ON
State Saved Saved in instrument state.
Initial S/W Revision A.07.00
Next Range
This key allows you to switch across ranges on the scan trace to see the setting of the RBW, VBW,
Attenuation, Int Preamp, Dwell Time, Step Size, Scan Time and Scan Points on the graph annotation and
meas bars. The green color outline will be moved as you switch across the ranges on the trace. This key
will do nothing for a single range scan, where the green outline will not be shown.
Key Path
View/ Display
Notes Front panel only.
604 EMI Receiver Mode Reference
