Keysight PXA X Series User Manual

12 Disturbance Analyzer Measurement
Meas Setup
Auto Sort
If this is turned On, the disturbance list is sorted based on the sorting order and sorting type as selected. If
this is Off, the disturbance will be added into the last row of the disturbance list.
Key Path
Meas Setup, Disturbance List, Sort Disturbances
Remote Command
CALCulate:DANalyzer:DLISt:SORT:AUTO ON|OFF|1|0
CALCulate:DANalyzer:DLISt:SORT:AUTO?
Example CALC:DAN:DLIS:SORT:AUTO 1 Turn on auto sorting
CALC:DAN:DLIS:SORT:AUTO?
Preset ON
State Saved Saved in instrument state
Range On|Off
Initial S/W Revision A.14.00
Delete All
Deletes all disturbances in the disturbance list. If you accessed this function from the front panel, the
following message will prompt you for confirmation to delete the selected disturbances from the
disturbance list..
This will delete all disturbances. Are you sure you want to do this?Please press Enter or OK to proceed.
Press ESC or Cancel to close this dialog.
Key Path
Meas Setup, Disturbance List
Remote Command
CALCulate:DANalyzer:DLISt:DELete:ALL
Example CALC:DAN:DLIS:DEL:ALL
Initial S/W Revision A.14.00
Comment
Sets an ASCII comment field for each disturbance in list, which will be shown in the “Comment” column of
the disturbance list. This value will be stored in the disturbance list exported file.
Key Path
Meas Setup, Disturbance List
Remote Command
CALCulate:DANalyzer:DLISt:COMMent <integer>,’string’
CALCulate:DANalyzer:DLISt:COMMent? <integer>
Example CALC:DAN:DLIS:COMM 1,’Is OK’
Preset “”
State Saved Saved in instrument state
Initial S/W Revision A.14.00
EMI Receiver Mode Reference 1063
