5 Mode Functions
Mode
Example INST:SEL CDMA1XEV
INST:NSEL 15
Initial S/W Revision Prior to A.02.00
802.16 OFDMA (WiMAX/WiBro)
Selects the OFDMA mode for general purpose measurements of WiMAX signals. There are several
measurements available in this mode.
If you are using the Help feature, this mode must be currently active to access its detailed information. If it
is not active, exit the Help feature (Esc key), select the mode, and re-access Help.
Key Path
Mode
Example INST:SEL WIMAXOFDMA
INST:NSEL 75
Initial S/W Revision Prior to A.02.00
802.16 OFDM (Fixed WiMAX)
Selects the 802.16 OFDM (Fixed WiMAX) mode. This mode allows modulation quality measurements of
signals that comply with IEEE 802.16a–2003 and IEEE 802.16–2004 standards, with flexibility to measure
nonstandard OFDM formats. Along with the typical digital demodulation measurement results, several
additional 802.16 OFDM unique trace data formats and numeric error data results provide enhanced data
analysis.
If you are using the Help feature, this mode must be currently active to access its detailed information. If it
is not active, exit the Help feature (Esc key), select the mode, and re-access Help.
Key Path
Mode
Example INST:SEL WIMAXFIXED
INST:NSEL 104
Initial S/W Revision A.02.00
89601 VSA
Selecting the 89601 VSA mode will start the 89600 VSA software. The 89600 VSA software is powerful,
PC-based software, offering the industry's most sophisticated general purpose and standards specific
signal evaluation and troubleshooting tools for R&D engineers. Even for proprietary and non-standard
signals in SATCOM or MILCOM applications, you can make signal quality measurements with customized
IQ constellation. Reach deeper into signals, gather more data on signal problems, and gain greater
insight.
• Over 35 general-purpose analog and digital demodulators ranging from 2FSK to 4096QAM
• Flexible and custom IQ and OFDM signal analysis for single carrier
EMI Receiver Mode Reference 233
