9 Strip Chart Measurement
Save
Dependencies Corrections are not supported by all Measurements. If in a Mode in which some Measurements
support it, this key will be grayed out in measurements that do not. The key will not show at all if no
measurements in the Mode support it.
This key will not appear unless you have the proper option installed in your instrument.
Readback Selected Correction
Backwards
Compatibility SCPI
:MMEMory:STORe:CORRection ANTenna | CABLe | OTHer | USER, <filename>
For backwards compatibility, ANTenna maps to 1, CABle maps to 2, OTHer maps to 3 and USER
maps to 4
Initial S/W Revision A.02.00
Correction Data File
A Corrections Data File contains a copy of one of the analyzer correction tables. Corrections provide a way
to adjust the trace display for predetermined gain curves (such as for cable loss).
Corrections files are text files in .csv (comma separated values) form, to make them importable into Excel
or other spreadsheet programs. The format for Corrections files is as follows.
Line
# Type of field Example Notes
1 File type, must be “Amplitude
Correction”
Amplitude Correction May not be omitted
2 File Description (in quotes) “Correction Factors for 11966E” 60 characters max; may be empty but
may not be omitted. If exceeds 60
characters, error –233 Too much data
reported
3 Comment (in quotes) “Class B Radiated” 60 characters max; may be empty but
may not be omitted. . If exceeds 60
characters, error –233 Too much data
reported
4 Instrument Version, Model # A.02.06,N9020A May be empty but may not be omitted
5 Option List, File Format
Version
K03 LFE EXM ,01 May be empty but may not be omitted
6 Freq Unit to be used for all
frequency values in the file
Frequency Unit,MHz assumed to be Hz if omitted
7 Antenna Unit Antenna Unit,None If omitted leaves the Antenna unit
unchanged. The amplitude unit in the
Antenna Unit field is a conversion factor
that is used to adjust the Y Axis Units of
the current mode, if the mode supports
Antenna Units. For more details on
antenna correction data, refer to the
Input/Output,Corrections key description.
Allowable values: dBuv/m, dBuA/m, dBG,
dBpT, None
EMI Receiver Mode Reference 689
