9 Strip Chart Measurement
Save
29749009.9 10.21771213
29750009.9 9.474250519
29751009.9 8.374183381
29752009.9 6.909049714
29753009.9 4.86714145
29754009.9 2.253837311
29755009.9 –0.937874114
29756009.9 –4.154472625
Save As . . .
When you press “Save As”, the analyzer brings up a Windows dialog and a menu entitled “Save As.” This
menu allows you to navigate to the various fields in the Windows dialog without using a keyboard or
mouse. The Tab and Arrow keys can also be used for dialog navigation.
See "To File . . ." on page 1096 in Save, State for a full description of this dialog and menu.
The default path for saving files is:
For all of the Trace Data Files:
My Documents\<mode name>\data\traces
For all of the Limit Data Files:
My Documents\<mode name>\data\limits
For all of the Measurement Results Data Files:
My Documents\<mode name>\data\<measurement name>\results
For all of the Capture Buffer Data Files:
My Documents\<mode name>\data\captureBuffer
Key Path
Save, Data
Mode All
Notes The key location is mode-dependent and will vary.
Brings up the Save As dialog for saving a <mode specific> Save Type. The save is performed
immediately and does not wait until the measurement is complete.
Initial S/W Revision Prior to A.02.00
Screen Image
Pressing Screen Image accesses a menu of functions that enable you to specify a format and location for
the saved screen image. It brings up a menu that allows you to specify the color scheme of the Screen
Image (Themes) or navigate to the Save As dialog to perform the actual save.
EMI Receiver Mode Reference 695
