3 Programming the Analyzer
STATus Subsystem
"Questionable Integrity Signal Enable" on page 130
"Questionable Integrity Signal Event Query" on page 131
"Questionable Integrity Signal Negative Transition" on page 131
"Questionable Integrity Signal Positive Transition" on page 131
Questionable Integrity Signal Condition
This query returns the decimal value of the sum of the bits in the Questionable Integrity Signal Condition
register.
The data in this register is continuously updated and reflects the current conditions.
Mode All
Remote Command
:STATus:QUEStionable:INTegrity:SIGNal:CONDition?
Example STAT:QUES:INT:SIGN:COND?
Preset 0
Status Bits/OPC
dependencies
Sequential command
Initial S/W Revision Prior to A.02.00
Questionable Integrity Signal Enable
This command determines which bits in the Questionable Integrity Signal Condition Register will set bits in
the Questionable Integrity Signal Event register, which also sets the Integrity Summary bit (bit 9) in the
Questionable Register. The variable <integer> is the sum of the decimal values of the bits you want to
enable.
Mode All
Remote Command
:STATus:QUEStionable:INTegrity:SIGNal:ENABle <integer>
:STATus:QUEStionable:INTegrity:SIGNal:ENABle?
Example STAT:QUES:INT:SIGN:ENAB 4 Burst Not Found will be reported to the Integrity Summary of the
Status Questionable register.
Preset 32767
Min 0
Max 32767
Status Bits/OPC
dependencies
Sequential command
Initial S/W Revision Prior to A.02.00
130 EMI Receiver Mode Reference
