10 Monitor Spectrum Measurement
Meas Setup
Key Path
Meas Setup, Signal List, Navigate
Notes Front panel only.
Dependencies Scroll Right
Initial S/W Revision A.13.00
Scroll Right
Scroll the signal list to the right.
Key Path
Meas Setup, Signal List, Navigate
Notes Front panel only.
Couplings Scroll Right
Status Bits/OPC
Dependencies
Scroll Right
Initial S/W Revision A.13.00
Signal à Meters (Move Meters to Current Signal)
Replace Frequency (Meters) with the frequency of the selected signal.
Key Path
Meas Setup, Signal List, Navigate
Remote Command
:CALCulate:SLISt:SET:METer <integer>
Example CALC:SLIS:SET:MET 12 Set Freq (Meters) to frequency of Signal #12
Notes If the signal list contains no data, an error is generated and this function cannot be performed.
If the selected signal is not in the list, an error is generated and this function cannot be performed.
Initial S/W Revision A.13.00
Mark Signals
This menu enables you to mark signals for further processing. A ticked checkbox appears next to the signal
number to distinguish them from unmarked signals.
Key Path
Meas Setup, Signal List
Initial S/W Revision A.13.00
Select Signal
Specifies the selected signal. The term “Selected signal” is used throughout this document to specify
which signal will be affected by the functions.
EMI Receiver Mode Reference 781
