5 Mode Functions
Mode
Vector Signal Analyzer (VXA)
The N9064A (formerly 89601X) VXA Vector signal and WLAN modulation analysis application provides
solutions for basic vector signal analysis, analog demodulation, and digital demodulation. The digital
demodulation portion of N9064A allows you to perform measurements on standard-based formats such as
cellular, wireless networking and digital video as well as general purpose flexible modulation analysis for
wide range of digital formats, FSK to 1024QAM, with easy-to-use measurements and display tools such as
constellation and eye diagram, EVM traces and up to four simultaneous displays. Analog baseband
analysis is available using the MXA and PXA with option BBA. Option 3FP WLAN has been discontinued.
N9064A honors existing 89601X licenses with all features and functionalities found on X-Series software
versions prior to A.06.00. Specifically:
N9064A–1 is equivalent to 89601X–205
N9064A–2 is equivalent to 89601X-AYA
If you are using the Help feature, this mode must be currently active to access its detailed information. If it
is not active, exit the Help feature (Esc key), select the mode, and re-access Help.
Key Path
Mode
Example INST:SEL VSA
INST:NSEL 100
Initial S/W Revision Prior to A.02.00
W-CDMA with HSPA+
Selects the W-CDMA with HSPA+ mode for general purpose measurements of signals following this
standard. There are several measurements available in this mode.
If you are using the Help feature, this mode must be currently active to access its detailed information. If it
is not active, exit the Help feature (Esc key), select the mode, and re-access Help.
Key Path
Mode
Example INST:SEL WCDMA
INST:NSEL 9
Initial S/W Revision Prior to A.02.00
WLAN
Selects the WLAN mode for general purpose measurements of signals following this standard. There are
several measurements available in this mode.
If you are using the Help feature, this mode must be currently active to access its detailed information. If it
is not active, exit the Help feature (Esc key), select the mode, and re-access Help.
Key Path
Mode
EMI Receiver Mode Reference 243
