10 Monitor Spectrum Measurement
Meas Setup
Preset OFF
State Saved Saved in instrument state
Range On|Off
Backwards
Compatibility SCPI
:CALCulate[1]|2:LIMit[1]|2|...|6:STATe
Backwards Compatibility
SCPI Notes
This command above is included for ESU compatibility. The suffix [1]|2 is irrelevant to the
measurement, they are added solely for remote language compatibility.
Initial S/W Revision A.13.00
Properties
Accesses a menu that lets you set the properties of the selected limit.
Key Path
Meas Setup, Limits
Initial S/W Revision A.13.00
Select Limit
Specifies the selected limit. The term “selected limit” is used throughout this document to specify which
limit will be affected by the functions.
Key Path
Meas Setup, Limits
Notes Front panel only. The selected limit is remembered even when not in the Limit Menu.
Preset Limit 1, not affected by Mode Preset, preset by Restore Mode Defaults.
State Saved Saved in instrument state
Initial S/W Revision A.13.00
Test Trace
Selects the trace that you want the limit to test. A limit is applied to one and only one trace.
A trace can have multiple limit lines simultaneously; in that case, only one upper limit line will affect the
color of the trace. Other limit lines will be displayed, and will affect the pass/fail status, but the trace will
not turn red if it crosses a secondary limit line.
Key Path
Meas Setup, Limits, Properties
Remote Command
:CALCulate:LLINe[1]|2|...|6:TRACe 1|2|3
:CALCulate:LLINe[1]|2|...|6:TRACe?
Example CALC:LLIN3:TRAC 2 Applies limit 3 to trace 2.
Notes When the trace display is off, the trace is not tested. The trace is tested only when the trace display
is on and Test Limits (see "Test Limits (All Limits)" on page 801) is on.
EMI Receiver Mode Reference 791
