8 Frequency Scan Measurement
Meas Setup
Preset 10
State Saved Saved in instrument state.
Min 0.1
Max 100
Initial S/W Revision A.07.00
Attenuation
Specifies the attenuation of the selected range. Only the mechanical attenuator is available in the
Frequency Scan measurement.
Key Path
Meas Setup, Scan Table
Remote Command
[:SENSe]:FSCan:SCAN[1]|2|...|10:INPut:ATTenuation <rel_ampl>
[:SENSe]:FSCan:SCAN[1]|2|...|10:INPut:ATTenuation?
Example FSC:SCAN2:INP:ATT 30 Set attenuation of Range 2 to 30dB.
FSC:SCAN2:INP:ATT?
Dependencies This key is grayed out during multi range scanning. If the grayed out key is pressed, an advisory
message is generated. If the equivalent SCPI command is sent, this same message is generated as
part of a “–221, Settings conflict; Function not available while running multirange scan” warning.
This key is grayed out during final measurement. If the grayed out key is pressed, an advisory
message is generated. If the equivalent SCPI command is sent, this same message is generated as
part of a “–221, Settings conflict” warning.
Preset 10dB
State Saved Saved in instrument state.
Min 0 dB
Max 50 dB (CXA)
60 dB (EXA)
70 dB (MXA, PXA)
Backwards
Compatibility SCPI
:SENSe1|SENSe2:SCAN[1]|2|...|10:INPut:ATTenuation
[:SENSe]:SCAN[1]|2|...|10:INPut:ATTenuation
Backwards Compatibility
SCPI Notes
This command above is included for ESU compatibility. The suffix 1|2 is irrelevant to the
measurement, they are added solely for remote language compatibility.
Initial S/W Revision A.07.00
Int Preamp
Specifies the Internal Preamp state of the selected range.
Key Path
Meas Setup, Scan Table
Remote Command
[:SENSe]:FSCan:SCAN[1]|2|...|10:POWer:GAIN[:STATe] ON | OFF | 1 | 0
EMI Receiver Mode Reference 465
