11 APD Measurement
Meas Setup
Delete Point
Pressing this key immediately deletes the currently selected point, whether or not that point is being
edited, or selected through Navigate. The point following the currently-selected point (or the point before
this point if there is none) will be selected.
Key Path
Meas Setup, Limits, Edit
Initial S/W Revision A.13.00
Test Limits (All Limits)
Selects whether test traces are tested against the displayed limits (i.e. those for which Limit On/Off is set
to On). If On, the PASS/FAIL box is displayed in the left corner of the Meas Bar.
This command only affects the display, and has no impact on remote behavior. Limit queries over SCPI test
the trace against the limit regardless of whether the trace or the limit is turned on (exception: the query
:CALCulate:APD:TRACe[1]|2|3:FAIL? tests only the limits that are turned on for that trace).
Key Path
Meas Setup, Limits
Remote Command
:CALCulate:APD:LLINe:TEST ON|OFF|1|0
:CALCulate:APD:LLINe:TEST?
Example CALC:APD:LLIN:TEST ON
CALC:APD:LLIN:TEST?
Preset On, not affected by Mode Preset, preset by Restore Mode Defaults.
State Saved Saved in instrument state.
Range On|Off
Initial S/W Revision A.13.00
Delete Limit
Deletes the currently selected limit line. Pressing Delete Limit purges the data from the limit line tables.
Limit data, including secondary parameters such as limit trace, description, comment, APD Method, etc..,
will be cleared and returned to factory preset settings.
When this key is pressed a prompt is placed on the screen that says “Please press Enter or OK key to
delete limit. Press ESC or Cancel to close this dialog.” The deletion is only performed if you press OK or
Enter. After a deletion, the informational message “Limit deleted” appears in the MSG line.
Key Path
Meas Setup, Limits
Remote Command
:CALCulate:APD:LLINe[1]:DELete
Example CALC:APD:LLIN3:DEL Deletes all data for limit line 3
Initial S/W Revision A.13.00
EMI Receiver Mode Reference 949
