5 Mode Functions
Mode Setup
State Saved Saved in instrument state
Range GRO|FLO
Initial S/W Revision A.13.50
V-network
Enables you to select the V-network that is controlled via the AUX IO port.
Key Path
Mode Setup, LISN Control
Remote Command
INPut[1]|2:LISN[:TYPE] FOURphase|ESH2Z5| ENV216 | OFF
INPut[1]|2:LISN[:TYPE]?
Example :INP:LISN FOUR
Notes FOURPhase and ESH2-Z5
R&S ESH2-Z5 (four phases and protective earth are controllable)
ENV216
R&S ENV216 (two phases and highpass are controllable)
OFF
Remote control deactivated
This query will return :-
FOUR when ESH2-Z5 is selected.
Preset Set to off on a "Restore Input/Output Defaults"
State Saved Saved in instrument state
Initial S/W Revision A.13.50
Phase
This command enables you to select the phase of the V-network that is used, which is controlled via the
AUX IO port. The permissible selection depends on the selected V-network.
Key Path
Mode Setup, LISN Control, ESH2Z5/ENV216
Remote Command
INPut[1]|2:LISN:PHASe L1|L2|L3|N
INPut[1]|2:LISN:PHASe?
Example :INP:LISN:PHAS L1
Couplings Phase N|L1|L2|L3 are grayed out with OFF whereas Phase L2|L3 are grayed out with ENV216. If the
grayed out key is pressed, an advisory message is generated. If the equivalent SCPI command is sent,
this same message is generated as part of a “–221, Setting Conflict; Function not available with
current LISN Type” warning.
Preset Set to N on a "Restore Input/Output Defaults"
State Saved Saved in instrument state
Range Phase N|Phase L1|Phase L2|Phase L3
262 EMI Receiver Mode Reference
