8 Frequency Scan Measurement
Meas Setup
Limit for ∆
Selects the limit used by each final detector or measure at marker to get the limit delta value that goes in
the Signal List. If you use the front panel to change the detector type, the following message will appear
to remind you that the change of detector will cause the data of the particular detector type column to be
discarded.
Changing limit for delta will discard the delta values, are you sure you want to do this?
Please press ENTER or OK to proceed. Press ESC or Cancel to close this dialog.
Key Path
Meas Setup, Detectors (Measure)
Remote Command
[:SENSe]:FSCan:FINal:DETector[1]|2|3:LDELta <limit Num>
[:SENSe]:FSCan:FINal:DETector[1]|2|3:LDELta?
Example :FSC:FIN:DET3:LDEL 2 Set limit line 2 to be used by detector 3.
Notes Not affected by Mode Preset, preset by Restore Mode Defaults.
Dependencies This key is grayed out during final measurement. If the grayed out key is pressed, an advisory
message is generated. If the equivalent SCPI command is sent, this same message is generated as
part of a “–221, Settings conflict” warning.
Preset
1|1|1
State Saved Saved in instrument state.
Range
1|2|3|4|5|6
Initial S/W Revision A.07.00
Autorange (Measure)
Accesses a menu that lets you decide whether or not to turn on the Autorange feature during the final
measurement.
Key Path
Meas Setup
Readback In square brackets, the state of Autorange then the state of Auto Preamp, separated by commas, as
[Rng:On, Pre:Off]
Initial S/W Revision A.07.00
Autorange
When autorange is selected, the attenuation will be increased automatically when an overload is detected
during the final measurement.
Key Path
Meas Setup, Autorange
Remote Command
[:SENSe]:FSCan:FINal:ATTenuation:AUTO ON|OFF|1|0
[:SENSe]:FSCan:FINal:ATTenuation:AUTO?
Example :FSC:FIN:ATT:AUTO 0
EMI Receiver Mode Reference 479
