10 Monitor Spectrum Measurement
Meas Setup
Key Path Meas Setup, Signal List, Sort Signals, By ∆
Remote Command
:CALCulate:SLISt:SORT:DLDelta DET1|DET2|DET3
:CALCulate:SLISt:SORT:DLDelta?
Example CALC:SLIS:SORT:DLD DET2
CALC:SLIS:SORT:DLD?
Dependencies Selecting the ∆ Detector type to be sorted (pressing the key or sending the equivalent SCPI
command) will turn on the Auto Sort state, even if that ∆ Detector type was already selected.
Preset DET1
State Saved Saved in instrument state
Range Detector 1|Detector 2|Detector 3
Initial S/W Revision A.13.00
By Time
Specifies that the elements in the signal list will be sorted based on time.
Key Path
Meas Setup, Signal List, Sort Signals
Example CALC:SLIS:SORT:TYPE TIME
Initial S/W Revision A.13.00
Sort Order
Chooses between ascending and descending order.
Key Path
Meas Setup, Signal List, Sort Signals
Remote Command
:CALCulate:SLISt:SORT:ORDer ASCending |DESCending
:CALCulate:SLISt:SORT:ORDer?
Example CALC:SLIS:SORT:ORD DESC
Dependencies Selecting the sort order (pressing the key or sending the equivalent SCPI command) will turn on the
Auto Sort state, even if that sort order was already selected.
Preset ASCending
State Saved Saved in instrument state
Initial S/W Revision A.13.00
Auto Sort
If this is turned on, the measurement will perform signal sorting based on the sorting order and sorting type
selected before each new signal is added. Otherwise, the signal will be added into the signal list in
descending order of the trace amplitude level.
788 EMI Receiver Mode Reference
