10 Monitor Spectrum Measurement
Save
Example MMEM:STOR:SCR:THEM FCOL
Readback Flat Color
Initial S/W Revision Prior to A.02.00
Flat Monochrome
Selects a format that is like Flat Color. But only black is used (no colors, not even gray), and no fill.
Key Path
Save, Screen Image, Themes
Example MMEM:STOR:SCR:THEM FMON
Readback Flat Mono
Initial S/W Revision Prior to A.02.00
Save As…
When you press “Save As”, the analyzer brings up a Windows dialog and a menu entitled “Save As.” This
menu allows you to navigate to the various fields in the Windows dialog without using a keyboard or
mouse. The Tab and Arrow keys can also be used for dialog navigation.
See "To File . . ." on page 1096 in Save, State for a full description of this dialog and menu.
The default path for Screen Images is
My Documents\<mode name>\screen.
where <mode name> is the parameter used to select the mode with the INST:SEL command (for example,
SA for the Spectrum Analyzer).
Key Path
Save, Screen Image
Notes Brings up Save As dialog for saving a Screen Image Save Type
Initial S/W Revision Prior to A.02.00
Mass Storage Catalog (Remote Command Only)
Key path
SCPI Only
Remote Command
:MMEMory:CATalog? [<directory_name>]
Notes The string must be a valid logical path.
Queries disk usage information (drive capacity, free space available) and obtains a list of files and
directories in a specified directory in the following format:
<numeric_value>,<numeric_value>,{<file_entry>}
It returns two numeric parameters and as many strings as there are files and directories. The first
parameter indicates the total amount of storage currently used in bytes. The second parameter
856 EMI Receiver Mode Reference
