4 Input/Output Functions
Input/Output
FEED:IQ:TYPE IQ
Preset IQ
State Saved Yes
This is unaffected by a Preset but is set to the default value on a "Restore Input/Output Defaults" or
"Restore System Defaults->All"
Range I+jQ | I Only | Q Only
Readback Text I+jQ | I Only | Q Only
Initial S/W Revision Prior to A.02.00
Remote Command
:INPut[1]:IQ:TYPE IQ|I|Q
:INPut[1]:IQ:TYPE?
Notes For R&S FSQ-B71 compatibility
Preset IQ
Initial S/W Revision Prior to A.02.00
I+jQ
Sets the signal input to be both the I and Q channels. The I and Q channel data will be combined as I + j * Q.
Key Path
Input/Output, I/Q, I/Q Path
Example Set the input to be both the I and Q channels, combined as I + j * Q.
FEED:IQ:TYPE IQ
Initial S/W Revision Prior to A.02.00
I Only
Sets the signal input to be only the I channel. The Q channel will be ignored. The data collected is still
complex. When the center frequency is 0 the imaginary part will always be zero, but for any other center
frequency both the real and imaginary parts will be significant.
Key Path
Input/Output, I/Q, I/Q Path
Example Set the input to be only the I channel.
FEED:IQ:TYPE IONL
Initial S/W Revision Prior to A.02.00
Q Only
Sets the signal input to be only the Q channel. The I channel will be ignored. The Q channel will be sent to
the digital receiver block as Q+j0. The receiver's output is still complex. When the center frequency is 0 the
EMI Receiver Mode Reference 161
