8 Frequency Scan Measurement
Meas Setup
Key Path
Meas Setup, Limits, Edit
Notes There is no value readback on the key
Min –1000 dBm
Max 1000 dBm
Initial S/W Revision A.02.00
Insert Point Below
Pressing this key inserts a point below the current point. The new point is a copy of the current point. And
becomes the current point The new point is not yet entered into the underlying table, and the data in the
row is displayed in light gray.
Key Path
Meas Setup, Limits, Edit
Initial S/W Revision A.02.00
Delete Point
This is an immediate action key. It will immediately delete the currently-selected point, whether or not
that point is being edited, and select Navigate. The point following the currently-selected point (or the
point preceding if there is none) will be selected.
Key Path
Meas Setup, Limits, Edit
Initial S/W Revision A.02.00
Copy from Limit
Copies an existing limit into the current limit, including all secondary parameters (Description, Associated
Trace, Type, Margin, Interpolation, Relative to CF/RL).
Key Path
Meas Setup, Limits, Edit
Remote Command
:CALCulate:FSCan:LLINe[1]|2|...|6:COPY LLINE1 | LLINE2 | LLINE3 |
LLINE4 | LLINE5 | LLINE6
Example
CALC:FSC:LLINE2:COPY LLINE1 Copies the data from limit 1 into limit 2.
Notes Auto return to the Edit menu.
Backwards
Compatibility SCPI
:CALCulate[1]|2:LIMit[1]|2|...|6:COPY
Backwards Compatibility
SCPI Notes
This command above is included for ESU compatibility. The suffix [1]|2 is irrelevant to the
measurement, they are added solely for remote language compatibility.
Initial S/W Revision A.07.00
EMI Receiver Mode Reference 491
