Lenze i550

Address Name / seng range / [default seng] Info
0x2946:003
(P340.03)
Speed limitaon: Upper speed limit source
(Speed limitaon: Uppspeed lim src)
•
From version 03.00
Selecon of the source for the upper speed limit.
0 Maximum frequency Upper speed limit = Maximum frequency 0x2916 (P211.00).
1 Fixed Limit 0.0 Hz Upper speed limit = 0.0 Hz.
2 Analog input 1 The upper speed limit is dened as analog signal via the analog input 1.
4Analog input 1 ^ 255
3 Analog input 2 The upper speed limit is dened as analog signal via the analog input 2.
4Analog input 2 ^ 260
4 Upper frequency limit Upper speed limit = seng in 0x2946:005 (P340.05) in [Hz].
5 Upper speed limit Upper speed limit = seng in 0x2946:001 (P340.01) in [vel. unit].
6 Network target velocity The upper speed limit is dened as process data object via network.
4Mappable parameters for exchanging setpoints and actual val-
ues ^ 299
201 Internal value (from version 05.03) Internal values of the manufacturer.
202 Internal value (from version 05.03)
203 Internal value (from version 05.03)
204 Internal value (from version 05.03)
205 Internal value (from version 05.03)
206 Internal value (from version 05.03)
0x2946:004
(P340.04)
Speed limitaon: Lower speed limit source
(Speed limitaon: Lowspeed lim src)
•
From version 03.00
Selecon of the source for the lower speed limit.
0 (-) Maximum frequency Lower speed limit = (-) Maximum frequency 0x2916 (P211.00).
1 Fixed Limit 0.0 Hz Lower speed limit = 0.0 Hz.
2 Analog input 1 The lower speed limit is dened as analog signal via the analog input 1.
4Analog input 1 ^ 255
3 Analog input 2 The lower speed limit is dened as analog signal via the analog input 2.
4Analog input 2 ^ 260
4 Lower frequency limit Lower speed limit = seng in 0x2946:006 (P340.06) in [Hz].
5 Lower speed limit Lower speed limit = seng in 0x2946:002 (P340.02) in [vel. unit].
6 Network target velocity The lower speed limit is dened as process data object via network.
4Mappable parameters for exchanging setpoints and actual val-
ues ^ 299
201 Internal value (from version 05.03) Internal values of the manufacturer.
202 Internal value (from version 05.03)
203 Internal value (from version 05.03)
204 Internal value (from version 05.03)
205 Internal value (from version 05.03)
206 Internal value (from version 05.03)
0x2946:005
(P340.05)
Speed limitaon: Upper frequency limit
(Speed limitaon: Upper freq.limit)
Device for 50-Hz mains: -1000.0 ... [50.0] ... 1000.0 Hz
Device for 60-Hz mains: -1000.0 ... [60.0] ... 1000.0 Hz
•
From version 03.00
Upper limit for the speed limitaon.
•
Seng is only eecve with the selecon "Upper frequency limit [4]"
in 0x2946:003 (P340.03).
0x2946:006
(P340.06)
Speed limitaon: Lower frequency limit
(Speed limitaon: Lower freq.limit)
Device for 50-Hz mains: -1000.0 ... [-50.0] ...
1000.0 Hz
Device for 60-Hz mains: -1000.0 ... [-60.0] ...
1000.0 Hz
•
From version 03.00
Lower limit for speed limitaon.
•
Seng is only eecve with the selecon "Lower frequency limit [4]"
in 0x2946:004 (P340.04).
0x2946:007
(P340.07)
Speed limitaon: Actual upper speed limit
(Speed limitaon: Act uppspeed lim)
•
Read only: x.x Hz
•
From version 03.00
Display of the current upper limit for speed limitaon.
0x2946:008
(P340.08)
Speed limitaon: Actual lower speed limit
(Speed limitaon: Act lowspeed lim)
•
Read only: x.x Hz
•
From version 03.00
Display of the current lower limit for speed limitaon.
Conguring the torque control
Basic seng
Speed limitaon
156
