214733 141 Revision A
1000722
A
B
C
Figure 4.58: Weight Box
10. Attach slow speed transport hitch (A) to the weight box
tongue (B) with drawbar pin, and secure with lynch pin.
Attach safety chain (C).
11. Connect hitch harness to electrical socket at front of
weight box.
1020166
Figure 4.59: Towing a Header
12. Start engine and raise weight box until tow bar is level.
Transport the header. Refer to Towing Header with
Windrower, page 139.
OPERATION
