214733 156 Revision A
1019408
A
Figure 4.92: Hydraulics Hoses in Storage Position
13. Place the hydraulics/electrical bundle (A) in storage position
on the header.
14. Back windrower slowly away from header.
1022271
A
B
C
Figure 4.93: Header Support
15. Reinstall clevis pin (B) into header support (C) and secure
with hairpin (A). Repeat for opposite side.
OPERATION
