MacDon M1170 - Page 443

214733 427 Revision A
Fault Codes
Telltale
Short
Description
Full Fault
Description
Recommended
Fix/Check Message
SA SPN
FMI
23 521489
1
Electrical System
Master Module Offline CAN 1 Offline Check Module connectors; if ok, Contact Dealer.
23 521489 2
Electrical System
Master Module Offline CAN 2 Offline Check Module connectors; if ok, Contact Dealer.
23 521489 3
Electrical System
Master Module Offline CAN 1 & 2 Offline Check Module connectors; if ok, Contact Dealer.
23 521489 4
Electrical System
Master Module Offline CAN 3 Offline Check Module connectors; if ok, Contact Dealer.
23 521489
5
Electrical System
Master Module Offline CAN 1 & 3 Offline Check Module connectors; if ok, Contact Dealer.
23 521489 6
Electrical System
Master Module Offline CAN 2 & 3 Offline Check Module connectors; if ok, Contact Dealer.
23 521489 7
Electrical System
Master Module Offline CAN 1 & 2 & 3 Offline
Check Module connectors & Module fuse; if ok, Contact Dealer.
23 521490
1
Electrical System
Ext. Module Offline
Firewall Extension Module Offline
Check Module connectors & Module fuse; if ok, Contact Dealer.
23 521491
1
Electrical System
Ext. Module Offline
Chassis Extension Module Offline
Check Module connectors & Module fuse; if ok, Contact Dealer.
23 521492 1
Electrical System
Display Offline CAN 1 Offline Check Module connectors; if ok, Contact Dealer.
23 521492 2
Electrical System
Display Offline CAN 2 Offline Check Module connectors; if ok, Contact Dealer.
23 521492 3
Electrical System
Display Offline CAN 1 & 2 Offline Check Module connectors; if ok, Contact Dealer.
23 521493 1
Electrical System
Relay Module Offline Roof Relay Module Offline
Check Module connectors & Module fuse; if ok, Contact Dealer.
23 521494 1
Electrical System
Relay Module Offline Chassis Relay Module Offline
Check Module connectors & Module fuse; if ok, Contact Dealer.
23 521495
1
Electrical System
Console Offline Console Offline
Check Module connectors & Module fuse; if ok, Contact Dealer.
23 521496 1
Electrical System
HVAC ECU Offine HVAC ECU Offine
Check Module connectors & Module fuse; if ok, Contact Dealer.
