214733 428 Revision A
Fault Codes
Telltale
Short
Description
Full Fault
Description
Recommended
Fix/Check Message
SA SPN
FMI
23 521497
1
Electrical
System
Engine ECM Offline
Engine Control Module
Offline
First check if cooling module door is open or
cooling module door sensor is defective. If not
then check engine control module connectors &
module fuse ; if ok, Contact Dealer.
23 521498
1
Electrical
System
CAN 1 Offline CAN 1 Offline Check CAN Harnessing; if ok, Contact Dealer.
23 521499 1
Electrical
System
CAN 2 Offline CAN 2 Offline Check CAN Harnessing; if ok, Contact Dealer.
23 521500 1
Electrical
System
CAN 3 Offline CAN 3 Offline Check CAN Harnessing; if ok, Contact Dealer.
25 168
1
Electrical
System
HVAC
Low voltage - Below normal,
most severe
Check HVAC power supply. Contact Dealer.
25 520193
5
Electrical
System
HVAC
Clutch low amps - Current
below normal
Inspect A/C clutch wiring for damage. Contact
Dealer.
25 520193 6
Electrical
System
HVAC
Clutch high amps - Current
above normal
Inspect A/C clutch wiring for damage. Contact
Dealer.
25 520194 3
Electrical
System
HVAC
Evaporator temp open
circuit - Voltage
above normal
Check temperature sensor and wiring at the
evaporator. Contact Dealer.
25 520194
4
Electrical
System
HVAC
Evaporator temp shorted -
Voltage below normal
Check temperature sensor and wiring at the
evaporator. Contact Dealer.
25 170 3
Electrical
System
HVAC
Cab temp open circuit -
Voltage above normal
Inspect cab temperature and wiring. Contact
Dealer.
25 170 4
Electrical
System
HVAC
Cab temp shorted - Voltage
below normal
Inspect cab temperature and wiring. Contact
Dealer.
25 442 3
Electrical
System
HVAC
Duct temp open circuit -
Voltage above normal
Check HVAC duct temperature sensor wiring.
Contact Dealer.
25 442 4
Electrical
System
HVAC
Duct temp shorted - Voltage
below normal
Check HVAC duct temperature sensor wiring.
Contact Dealer.
104 111 1
Windrower Engine Coolant Low Below Normal Most Severe
Coolant Level - Data Valid But Below Normal
Operational Range.
REFERENCE
