MacDon M1170 - Page 445

214733 429 Revision A
Fault Codes
Telltale
Short
Description
Full Fault
Description
Recommended
Fix/Check Message
SA SPN
FMI
104
111 17
Windrower Engine Coolant Low Below Normal Least Severe
Coolant Level - Data Valid But Below Normal Operating Range.
104 521000 3
Electrical System
Fuel Level Sender Low Alarm
Sensor voltage below 0.5 V. Check sensor power supply. Replace sensor if necessary.
104 521000
4
Electrical System
Fuel Level Sender High Alarm
Sensor voltage above 4.5 V. Check for wiring damage. Replace sensor if necessary.
104 521000
5
Electrical System
Fuel Level Sender
Low Error
Sensor voltage below 0.5 V. Check sensor power supply. Replace sensor if necessary.
104 521000 6
Electrical System
Fuel Level Sender High Error
Sensor voltage above 4.5 V. Check for wiring damage. Replace sensor if necessary.
104 521000 8
Electrical System
Fuel Level Sender
Vref Error
Reference voltage error. Check sensor wiring for damage.
104 521003 3
Electrical System
GSL Position
Low Alarm
Sensor voltage below 0.5 V. Check sensor power supply. Contact dealer to adjust and re-calibrate or replace sensor if necessary.
104 521003 4
Electrical System
GSL Position
High Alarm
Sensor voltage above 4.5 V. Check for wiring damage. Contact dealer to adjust and re- calibrate or replace sensor if necessary.
104 521003
5
Electrical System
GSL Position
Low Error
Sensor voltage below 0.5 V. Check sensor power supply. Contact dealer to adjust and re-calibrate or replace sensor if necessary.
104 521003 6
Electrical System
GSL Position
High Error
Sensor voltage above 4.5 V. Check for wiring damage. Contact Dealer to adjust and re- calibrate or replace sensor if necessary.
104 521003 8
Electrical System
GSL Position
Vref Error
Reference voltage error. Check sensor wiring for damage.
104 521006 5
Electrical System
Hyd Oil Temp Sensor
Low Error
Sensor voltage below 50 mV. Check sensor power supply. Replace sensor if necessary.
104 521006 6
Electrical System
Hyd Oil Temp Sensor High Error
Sensor voltage above 1300 mV. Check for wiring damage. Replace sensor if necessary.
104 521006 8
Electrical System
Hyd Oil Temp Sensor
Vref Error
Reference voltage error. Check sensor wiring for damage.
