214733 430 Revision A
Fault Codes
Telltale
Short
Description
Full Fault
Description
Recommended
Fix/Check Message
SA SPN
FMI
104 521383 15
Windrower Hydraulic Oil Hot Above Normal Least Severe
Clean cooler cores with compressed air. If
condition persists with clean cores, contact
dealer.
104 521383 0
Windrower Hyd Oil Very Hot Above Normal Most Severe
Clean cooler cores with compressed air. If
condition persists with clean cores, contact
dealer. Continued operation may lead to machine
damage.
104 521387 0
Windrower Oil Charge Press High Above Normal Most Severe
Charge pressure relief valve may be misadjusted
or damaged. Contact dealer.
104 521387
17
Windrower Oil Charge Press Low Below Normal Least Severe
Charge pressure relief valve may be misadjusted
or damaged. Contact dealer.
104 521387
1
Windrower Oil Charge Press Low Below Normal Most Severe
Shut down engine. Charge pressure relief valve
may be misadjusted or damaged. Contact Dealer.
104 521021 3
Electrical
System
Reel Height Low Alarm
Sensor voltage below 0.5 V. Check sensor power
supply. Adjust and re-calibrate or replace sensor
if necessary.
104 521021 4
Electrical
System
Reel Height High Alarm
Sensor voltage above 4.5 V. Check for wiring
damage. Adjust and re-calibrate or replace
sensor if necessary.
104 521021
5
Electrical
System
Reel Height
Low Error
Sensor voltage below 0.5 V. Check sensor power
supply. Adjust and re-calibrate or replace sensor
if necessary.
104 521021 6
Electrical
System
Reel Height High Error
Sensor voltage above 4.5 V. Check for wiring
damage. Adjust and re-calibrate or replace
sensor if necessary.
104 521021 8
Electrical
System
Reel Height Vref Error
Reference voltage error. Check sensor wiring for
damage.
104 521024 3
Electrical
System
Reel Fore-Aft Low Alarm
Sensor voltage below 0.5 V. Check sensor power
supply. Adjust and re-calibrate or replace sensor
if necessary.
104 521024 4
Electrical
System
Reel Fore-Aft High Alarm
Sensor voltage above 4.5 V. Check for wiring
damage. Adjust and re-calibrate or replace
sensor if necessary.
