214733 431 Revision A
Fault Codes
Telltale
Short
Description
Full Fault
Description
Recommended
Fix/Check Message
SA SPN
FMI
104 521024
5
Electrical System
Reel Fore-Aft
Low Error
Sensor voltage below 0.5 V. Check sensor power supply. Adjust and re-calibrate or replace sensor if necessary.
104 521024 6
Electrical System
Reel Fore-Aft High Error
Sensor voltage above 4.5 V. Check for wiring damage. Adjust and re-calibrate or replace sensor if necessary.
104 521024 8
Electrical System
Reel Fore-Aft Vref Error
Reference voltage error. Check sensor wiring for damage.
104 521027 3
Electrical System
Lateral Tilt Low Alarm
Sensor voltage below 0.5 V. Check sensor power supply. Adjust and re-calibrate or replace sensor if necessary.
104 521027 4
Electrical System
Lateral Tilt High Alarm
Sensor voltage above 4.5 V. Check for wiring damage. Adjust and re-calibrate or replace sensor if necessary.
104 521027
5
Electrical System
Lateral Tilt
Low Error
Sensor voltage below 0.5 V. Check sensor power supply. Adjust and re-calibrate or replace sensor if necessary.
104 521027 6
Electrical System
Lateral Tilt High Error
Sensor voltage above 4.5 V. Check for wiring damage. Adjust and re-calibrate or replace sensor if necessary.
104 521027 8
Electrical System
Lateral Tilt Vref Error
Reference voltage error. Check sensor wiring for damage.
104 521030 3
Electrical System
Left Float Cyl.
Low Alarm
Sensor voltage below 0.5 V. Check sensor power supply. Adjust and re-calibrate or replace sensor if necessary.
104 521030 4
Electrical System
Left Float Cyl. High Alarm
Sensor voltage above 4.5 V. Check for wiring damage. Adjust and re-calibrate or replace sensor if necessary.
104 521030
5
Electrical System
Left Float Cyl.
Low Error
Sensor voltage below 0.5 V. Check sensor power supply. Adjust and re-calibrate or replace sensor if necessary.
104 521030 6
Electrical System
Left Float Cyl. High Error
Sensor voltage above 4.5 V. Check for wiring damage. Adjust and re-calibrate or replace sensor if necessary.
REFERENCE
