Fault Codes
Telltale
Short
Description
Full Fault
Description
Recommended
Fix/Check Message
SA SPN
FMI
104 521030 8
Electrical
System
Left Float Cyl. Vref Error
Reference voltage error. Check sensor wiring for
damage.
104 521033 3
Electrical
System
Converyor Pressure
Low Alarm
Sensor voltage below 0.5 V. Check sensor power
supply and replace sensor as necessary. Ensure
that DWA option (in Attachments menu) is
checked off only if it is in fact installed.
104 521033
4
Electrical
System
Conveyor Pressure
High Alarm
Sensor voltage above 4.5 V. Check for wiring
damage and replace sensor as necessary. Ensure
that DWA option (in Attachments menu) is
checked off only if it is in fact installed.
104 521033
5
Electrical
System
Conveyor Pressure Low Error
Sensor voltage below 0.5 V. Check sensor power
supply and replace sensor as necessary. Ensure
that DWA option (in Attachments menu) is
checked off only if it is in fact installed.
104 521033 6
Electrical
System
Conveyor Pressure
High Error
Sensor voltage above 4.5 V. Check for wiring
damage and replace sensor as necessary. Ensure
that DWA option (in Attachments menu) is
checked off only if it is in fact installed.
104 521033 8
Electrical
System
Conveyor Pressure
Vref Error
Reference voltage error. Check sensor wiring for
damage. Ensure that DWA option (in
Attachments menu) is checked off only if it is in
fact installed.
104 521036 3
Electrical
System
Right Float Cyl. Low Alarm
Sensor voltage below 0.5 V. Check sensor power
supply. Adjust and re-calibrate or replace sensor
if necessary.
104 521036
4
Electrical
System
Right Float Cyl. High Alarm
Sensor voltage above 4.5 V. Check for wiring
damage. Adjust and re-calibrate or replace
sensor if necessary.
104 521036 5
Electrical
System
Right Float Cyl.
Low Error
Sensor voltage below 0.5 V. Check sensor power
supply. Adjust and re-calibrate or replace sensor
if necessary.
104 521036 6
Electrical
System
Right Float Cyl. High Error
Sensor voltage above 4.5 V. Check for wiring
damage. Adjust and re-calibrate or replace
sensor if necessary.
