214733 433 Revision A
Fault Codes
Telltale
Short
Description
Full Fault
Description
Recommended
Fix/Check Message
SA SPN
FMI
104 521036 8
Electrical
System
Right Float Cyl.
Vref Error
Reference voltage error. Check sensor wiring for
damage.
104 521039 3
Electrical
System
Knife Pressure Low Alarm
Sensor voltage below 0.5 V. Check sensor power
supply and replace sensor as necessary.
104 521039 4
Electrical
System
Knife Pressure High Alarm
Sensor voltage above 4.5 V. Check for wiring
damage and replace sensor as necessary.
104 521039
5
Electrical
System
Knife Pressure
Low Error
Sensor voltage below 0.5 V. Check sensor power
supply and replace sensor as necessary.
104 521039 6
Electrical
System
Knife Pressure High Error
Sensor voltage above 4.5 V. Check for wiring
damage and replace sensor as necessary.
104 521039 8
Electrical
System
Knife Pressure Vref Error
Reference voltage error. Check sensor wiring for
damage.
104 521042 3
Electrical
System
Reel Pressure Low Alarm
Sensor voltage below 0.5 V. Check sensor power
supply. Adjust and re-calibrate or Replace sensor
if necessary.
104 521042
4
Electrical
System
Reel Pressure High Alarm
Sensor voltage above 4.5 V. Check for wiring
damage. Adjust and re-calibrate or Replace
sensor if necessary.
104 521042 5
Electrical
System
Reel Pressure
Low Error
Sensor voltage below 0.5 V. Check sensor power
supply. Adjust and re-calibrate or Replace sensor
if necessary.
104 521042 6
Electrical
System
Reel Pressure High Error
Sensor voltage above 4.5 V. Check for wiring
damage. Adjust and re-calibrate or Replace
sensor if necessary.
104 521042 8
Electrical
System
Reel Pressure Vref Error
Reference voltage error. Check sensor wiring for
damage.
104 521045 3
Electrical
System
Header Tilt Low Alarm
Sensor voltage below 0.5 V. Check sensor power
supply. Adjust and re-calibrate or Replace sensor
if necessary.
104 521045
4
Electrical
System
Header Tilt High Alarm
Sensor voltage above 4.5 V. Check for wiring
damage. Adjust and re-calibrate or Replace
sensor if necessary.
